Description
PRODUCT INFO
ApplicationsDesigned for continuous air over applications such as direct drive residential, commercial and industrial air conditioners, fan and blowers
FeaturesAutomatic thermal protection. All-angle mount. Sleeve or ball bearing. 60°C ambient. Reversible rotation. Full flatted shaft. Rheem mounting holes in shell, mounting hardware included. Capacitor requirement noted on motor label
- Life-Line – Direct Drive Fan and Blower Motor
- 5.6″ Diameter – 48 Frame
- Permanent Split Capacitor (PSC); Capacitor Required: 15 Mfd-370 Volts (Not Supplied with Motor)
- Thermally Protected
- Open Air Over
- Class B Insulation, 40°C Ambient
- Sleeve Bearing
- 1/2″ Diameter Shaft with Flat
- 38″ Leads
- Extended Clampbolts, Belly Band, Mounting Holes in Shell
| Nameplate Specifications | |
| UPC | 815585020400 |
| Output HP | 1/2 Hp |
| Frequency | 60 Hz |
| Current | 5.70 A |
| Service Factor | 1 |
| Duty | Continuous Air Over |
| Frame | 48 |
| Thermal Protection | Thermally Protected |
| UL | Recognized |
| Voltage | 115 V |
| Speed | 1075 rpm |
| Phase | 1 |
| Insulation Class | B |
| Enclosure | Open Air Over |
| Ambient Temperature | 40 °C |
| CSA | Y |
