Description
Connecticut Electric replacement circuit breaker for Federal Pacific Electric type NA (thick) breakers. Classified and approved for use in Federal Pacific load centers. ETL Listed. 10,000 AIC. 2-pole, 100A
150
| UPC | 094925001181 |
|---|---|
| UNSPSC | 39121601 |
| Country of Origin | CHN |
| Amperage Rating: | 100 AMP |
| Material: | DMC |
| Number Of Poles: | 2 |
| Type: | UBIF TYPE NC THICK REPLACEMENT |
| Voltage Rating: | 120/240 VAC |
| Actuator: | Handle |
| Amperage Rating: | 100 AMP |
| Connection: | Push On |
| Enclosure: | Appropriate OEM Panelboard i.e Federal Pacific |
| Environmental Conditions: | Determined by panel for product |
| Frequency Rating: | 50/60 Hz |
| Height: | 2.75 in |
| Interrupt Rating: | 10000 AIC |
| Length: | 4.5 in |
| Load Rating: | 1 |
| Material: | DMC |
| Number Of Poles: | 2 |
| Operating Temperature: | 40 Celsius |
| Phase: | 1 |
| Standard: | ETL Listed |
| Sub Brand: | UBIF |
| Trip Range: | None |
| Trip Type: | Thermal |
| Type: | UBIF TYPE NC THICK REPLACEMENT |
| Voltage Rating: | 120/240 VAC |
| Width: | 2 in |
