Description
PRODUCT INFO
Applications
Designed as replacements for direct drive furnace blower motors, air conditioners, exhaust fans and other applications
FeaturesAutomatic thermal protection. Reversible rotation. Horizontal mount. 2-1/4″ resilient rings. 26″ long leads with 1/4″ straight terminals. 1/2″ x 4″ long flatted shaft with flat 3-1/2″ long. 3/4″ long studs on 5.12″ bolt circle, #10-32 thread on shaft end
- Open frame and brackets
- Multi-speed model
- Grommeted lead exit, Weather resistant reversing plug
- 2-1/4” resilient ring mounting (base not included, see Accessories section)
- 2 1/2” adapter rings supplied, shipped loose in box
- 3/4″ thru-bolts, shaft end, 30” long leads
- Automatic reset thermal protector
- Capacitor not included, see Accessories section
- HM106-0034 replaces the following brands and item numbers: Designed as replacements for direct drive furnace blower motors, air conditioners, exhaust fans and other applications
| Nameplate Specifications | |
| UPC | 722856038555 |
| Output HP | 1/3 Hp |
| Frequency | 60 Hz |
| Current | 3.3-3.3 A |
| Service Factor | 1 |
| Duty | Continous |
| Frame | 48 |
| Thermal Protection | Automatic Lock Rotor Only |
| UL | Recognized |
| Voltage | 208-230 V |
| Speed | 1075 rpm |
| Phase | 1 |
| Insulation Class | B |
| Enclosure | Open Air Over |
| Ambient Temperature | 40 °C |
| CSA | Y |
